PAM2422AECADJR:  Conv DC-DC Single Step Up 2.7V to 5.5V 8-Pin SOP T/R - Tape and Reel

Package: SOP-8

Mfr. Part#: PAM2422AECADJR



Quality: 100% Original

Warranty: 180 days

Buy now

The PAM242x devices are high-performance, fixed frequency, current-mode PWM step-up DC/DC converters that incorporate internal power MOSFETs. The PAM242x includes an integrated power MOSFET that supports peak currents of up to 3A/4.5A/5.5A.The PAM242x utilizes simple external loop compensation allowing optimization between component size, cost and AC performance across a wide range of applications . Additional functions include an externally programmable soft-start function for easy inrush current control, internal over-voltage protection (OVP), cycle-by-cycle current limit protection, under voltage lock-out and thermal shutdown.

Key Features

  • Greater than 90% Efficiency
  • Adjustable Output Voltage Up to 24V
  • Internal 24V Power MOSFET
  • Peak Current 3A,4.5A,5.5A
  • 520kHz Frequency
  • Built-in Over-Voltage Protection (OVP)
  • Open Protection
  • Programmable Soft-Start Function
  • Thermal Shutdowns
  • Under-Voltage-Lockout
  • Over-Current Protection
  • SOP-8(EP) Package

Part Status Active
Function Step-Up
Output Configuration Positive
Topology Boost
Output Type Adjustable
Number of Outputs 1
Voltage - Input (Min) 2.7V
Voltage - Input (Max) 5.5V
Voltage - Output (Min/Fixed) 2.7V
Voltage - Output (Max) 24V
Current - Output 4.5A (Switch)
Frequency - Switching 520kHz
Synchronous Rectifier No
Operating Temperature -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width) Exposed Pad
Supplier Device Package 8-SO-EP
